Canon imagePROGRAF iPF6400

5339B002

Canon imagePROGRAF iPF6400

Brand: Canon

Series: iPF

Model: 6400

Type: Ink

Click Here to View the Brochure

Call for price

SHARE
Share

Description

Features :

  • Canon’s LUCIA EX Ink set offers a brilliant range of vibrant colors, smooth gradations and transitions, with incredibly fine details.
  • The Color Calibration Management Console enables color calibration targets created using the iPF6450 printer with optional spectrophotometer to be linked across the entire line of new 12 color imagePROGRAF devices.
  • This printer includes an upgraded, built-in color densitometer that’s designed to offer even more precise calibration and color matching.
  • High Speed Printing with Fewer Passes
  • The tint and tone controls over the four monochromatic shades allow a user to create even more expressive blacks with smoother gradations – especially in dark areas.
  • Large Ink Tank Capacity
  • Gigabit Ethernet Support
  • Fast data transfer will help exceptionally high measures of productivity.

Buffer Ram :

  • 384 MB

Additional information

Brand

Model

Series

Width

Condition

Ink Category

Print Type

12-Color 24-inch Printer

OS Compatibility

Windows XP (32/64-bit), Server 2003 (32/64-bit),
Server 2008 (32/64-bit), Windows Vista® (32/64-bit),
Windows 7 (32/64-bit); Macintosh® OS X
10.5.8 – 10.7x

Ink Capacity

130ml/300ml per color

Maximum Media Roll Diameter

5.9 (150mm)

Print Languages

GARO (Canon Proprietary)

Physical Dimensions

39.4” (H) x 48.3” (W) x 27.6” (D)

Weight

Approximately 154 lbs. with stand

Print-Heads

PF-05 (2)

Technology

FINE (Full-photolithography Ink-jet Nozzle Engineering)

Print Resolution (Max.)

Up to 2400 x 1200 dpi

Memory

Ink Type

LUCIA EX Ink (Pigment-based)

Ink Tank

PFI-106 (130ml):
BK, MBK, C, M, Y, PC,
PM, GY, PGY, R, G, B

PFI-206 (300ml):
BK, MBK, C, M, Y, PC,
PM, GY, PGY, R, G, B

Colors

Cyan, Photo Cyan, Magenta, Photo Magenta,
Yellow, Black, Matte Black, Gray, Photo Gray, Red,
Green, Blue

Ink Tank Shipped with Printer

12 Colors (90ml Starter Tank Each Color)

Media Feed

Top-loading Roll Feed
One Roll, Front Output

Top-loading Manual Feed
One Sheet, Front Output

Front-loading Manual Feed
One Sheet, Front Output

Media Width

8" – 24" (Cut Sheet and Roll)

Minimum Media Length

Top-loading Roll Feed
8" (203mm)

Top-loading Manual Feed
11.0" (279mm)

Front-loading Manual Feed
13.8" (350mm)

Maximum Print Length

Manual Feed
63" (1.6m)

Roll Feed
59' (18m)*

Front-Loading Manual Feed
36" (914mm)

Borderless Printing Widths (Roll Media Only)

10"/14"/16"/17"/24"/B4 [9.84"(250mm)]/
A2 [16.54"(420mm)]/ B2 [20.28"(515mm)]/
A1 [23.38"(594mm)]

Printer Stand

Standard

Media Thickness

Top-loading Manual Feed
0.07mm – 0.8mm (2.8mil – 31.4mil)

Front-loading Manual Feed
0.5mm – 1.5mm (19.6mil – 59.0mil)

Top-loading Roll Feed
0.07mm – 0.8mm (2.8mil – 31.4mil)

Media Core Sizes

2" or 3" Core (with Supplied Adapter)

Printable Margins

Manual Feed (Top/Front)

Leading and Left/Right Edges: 0.12" (3mm)
Trailing Edge, Front Feed: 0.90" (23mm)
Trailing Edge, Top Feed: 0.12" (3mm) Except
Art Paper 0.90" (23mm)
Roll Feed, All Sides: 0.12" (3mm) or 0" for Borderless

Bundled Software

Printing Software –
Canon Printer Driver, Print Plug-in for Photoshop,**
Print Plug-in for DPP,*** Printer Driver Extra Kit
(Free Layout, imageRUNNER Linking Function),
Print Plug-in for Microsoft Office

Applications –
PosterArtist Lite

Utilities –
imagePROGRAF Status Monitor (Windows),
Print Monitor (Macintosh), Media Configuration
Tool, Remote UI, Accounting Manager, Color
Calibration Management Console

Printer Language

GARO (Canon Proprietary)

Interface

USB 2.0 High-Speed
10/100/1000Base-T/TX

Acoustic Noise

Operation 47dB or Less

Power Supply

AC 100-240V (50-60Hz)

Power Consumption

Maximum
100W or Less

Standby (100-120V)
6W or Less

Power Off
.5W or Less (compliant with executive order)

Certifications

UL, FCC Class B, ENERGY STAR®

Operational Environment

Temperature
59 – 86 F° (15 – 30 C°)

Relative Humidity
10 – 80% (No Condensation)

Dimensions with Stand (H x W x D)

39.4" x 48.3" x 34.3"

Weigh

Approx. 154 lb.

User-Replaceable Items

Print-Head (PF-05)
Maintenance Cartridge (MC-16)

Options

Roll Holder Set RH2-25
PosterArtist (PC Only)
