| Brand |
Contex |
| Model |
IQ Flex |
| Scan Sizes (Maximum standard sheet size) |
Arch C-size (18” x 24”) / ISO A2 (457 x 610 mm) |
| Scan Sizes (Maximum image area ) |
19.2” x 25.2” (487mm x 639.6mm) |
| Scan Sizes (Oversize scanning (2-stage scanning) ) |
Arch D-size (24” x 36”) / ISO A1 (610 x 914 mm) |
| Color Scanning Speed |
|
| RGB Color or Grayscale/ Monochrome at 200dpi, full image area scan |
6 seconds |
| Capture Technology |
|
| Optical resolution |
1200 x 1200 dpi |
| Maximum Resolution |
9600 dpi |
| Sensor Technology |
CIS Contex CleanScan+ |
| Maximum Media Thickness |
Limited only by capacity |
| Accuracy |
0.1% +/- 1 pixel |
| Data Capture (color/mono) |
48-bit / 16-bit |
| Color Space |
Adobe RGB / Device RGB / RAW RGB / sRGB |
| Effective number of Pixels |
23017 pixels (w) x 30217 pixels (l) |
| Capacities |
|
| Document weight |
Up to 10kg (22lbs) evenly distributed over the whole scan glass area |
| Document thickness |
No specified limit but objects must maintain contact with the glass, completely cover the glass or be effectively
covered by the scanner lid and not exceed the maximum document weight (see above) |
| Connectivity |
|
| Supported OS |
Windows 10, 8, 7 and Vista |
| Cloud Destinations |
Dropbox, Google Drive, Microsoft OneDrive, Box.com, rainforest365 ready |
| Network |
Wireless (IEEE 802.11b, IEEE 802.11g, IEEE 802.11n) up to 150Mbps / Gigabit Ethernet |
| Included software (download) |
Contex LINK networking and cloud access utility
WIDEsystem driver and scanner maintenance utility |
| Optional software |
Nextimage5, AutoCAD® , Microstationtm, ArcGIStm and all other CAD, GIS and 64-bit TWAIN application driver included
for use with EDM and other imaging software |
| Nextimage additional file formats |
TIF, JPG, PDF, PDF/A, DWF, CALS, BMP, JPEG-2000(JP2), JPEG2000 Extended(JPX), TIF-G3,
TIF-G4, multi-page PDF and others |
| Embedded Controller |
|
| Touch Screen |
7” Multi Touch Screen. 800 x 480 pixels |
| Processor |
Atom Quad-Core |
| Memory (ram/flash) |
8GB / 16 GB |
| Destinations |
Network PCs, Cloud, Email, Copy and USB key (USB3.0) |
| File formats |
PDF, PDF/A, TIF and JPG |
| Supported printers |
Selected HP, Canon and EPSON wide format printers. See full list at Contex.com |
| Power, weight and dimensions |
|
| Power Consumption (Ready / Sleep Mode / Scanning) |
Max 10W / 0.5W / 23W – ENERGY STAR certified |
| Power Requirements |
100 – 240V, 60/50Hz, 80W |
| Unpacked Weight / Dimensions (L x W x H5) |
35 kg (77Ibs) / 661 mm (26”) x 1176 mm (46”) x 194 mm (8”) |
| Packed Weight / Dimensions (L x W x H) |
43 kg (95Ibs) / 838 mm (33”) x 1320 mm (52”) x 305 mm (12”) |
| Packaging |
EPE foam shock protection frame inside thick cardboard box |
| What’s in the box |
Scanner, 2m Ethernet cable, Wi-Fi USB dongle, external power supply, quick guide: installation,
quick guide: scanner cleaning and calibration, calibration sheet and cleaning cloth |
| Environmental |
ENERGY STAR© Certified, EuP (EU), WEEE (EU), RoHS (EU) and REACH (EU) |
|
1.Average speed at 200dpi. Scanning speeds depend on scan destination, dpi and network configuration. Contex recommends Intel Core Duo, Core 2 Duo, or better processors, 2GB RAM. Speed
tests performed using Nextimage software, PC with Intel Core i5-2500 Quad processor, 8GB RAM, 7200rpm HDD, Windows 7 64-bit Ultimate.
2.Color spaces: sRGB with embedded controller, other color spaces available using Nextimage software.
3.Contex LINK software operational specifications
4.Contex applications create industry standard raster file formats that can be used in any CAD or GIS application.
5.Scanner lid in lowered position with touch screen raised.
All trademarks remain the property of their respective holders, and are used only to directly describe the product being provided. Their use in no way indicates any relationship between Contex and
the holders of the said trademarks. |
