Canon imagePROGRAF TZ-30000 MFP Z36
Canon imagePROGRAF TZ-30000 MFP
Canon imagePROGRAF TZ 30000 side
Canon imagePROGRAF TZ 30000
Canon imagePROGRAF TZ-30000 MFP Z36

Canon imagePROGRAF TZ-30000 Series

**New Canon imagePROGRAF TZ-30000 Series**

Brand: Canon

Model: iPF TZ-30000

Series: TZ-30000

System Type: Printer Only or MFP Z36

Type: Ink

Click Here to View the Brochure

Call for price

SHARE
Share

Description

Canon imagePROGRAF TZ-30000 Series.

The Fastest imagePROGRAF. Ever.

Check it out here.

The fastest printing speed of any imagePROGRAF printer to date at up to 4-D size prints per minute. Designed with many “Canon First” technologies built in such as twin carriage motors, an integrated top stacker that utilizes an air flow system and a dual roll media system with intelligent media handling.

Offering high-speed printing, security features and advanced media handling, these new solutions are designed to benefit a variety of Production CAD markets including architecture, engineering, government, manufacturing – just to name a few – at a low acquisition cost.

Highlights of the imagePROGRAF TZ-30000 Series include:

  • Speed – 14 sec/D, 4 D/min, 244 D/hour
    • The ability to output the 1st print from the ready state in 19 second allows the TZ to print 5 D sheets before the competition wakes up from sleep mode
    • Utilizes twin carriage motors
  • Stacking – Integrated 100 sheet top stacker
    • Air flow system keeps prints neatly in place
    • Face down stacking for confidentiality
  • Media Handling – Dual roll system with advanced features
    • Intelligent media handling for auto media loading with type, width, and length detection
    • Remaining paper length display indicator /LED light display indicates paper is running low
    • Load 2nd roll while the printer is printing on other roll with the Smart Roll Set
  • MFP Option – New TZ Scanner Co-developed by Canon and Global Scanning
    • 6ips Color; 13ips Monochrome scan speeds
    • Large 15.6” Touchscreen System Controller
  • Software – Enhanced workflow solutions available including
    • TZ Printer Driver and CPP Driver Select
    • Direct Print Plus
    • CPP Publisher Select

Read more on Canon imagePROGRAF TZ-30000 Series..

Additional information

Brand

Model

Series

System Type

,

Printer Display

4.3” Color LCD Touch-screen

MFP Display

15.6” Color LCD Touch-screen

Memory

Number of Nozzles

Matte Black: 5,120 Nozzles
Other Colors: 2,560 Nozzles/Color

Maximum Print Resolution

Up to 2400 x 1200 dpi

Print Speed

Up to 4 D Prints/Minute*
Up to 244 D Prints/Hour**

Print Head

PF-06

Ink/Tonar

Ink Type

Pigment: Matte Black (MBK), Cyan (C), Magenta
(M), Yellow (Y), Black (BK)

Interface

USB B Port

Type: Built-in (Hi-speed USB)
Mode: Full Speed (12-Mbit/sec.), High Speed
(480-Mbit/sec.), Bulk Transfer
Connector Type: Series B (4 Pins)
USB A Port: USB Memory (Direct Print)

Gigabit Ethernet

Type: Built-in
Standard: IEEE 802.3u 100Base-TX/Auto-Negotiation
IEEE 802.3ab 1000Base-T/Auto-Negotiation
IEEE 802.3x Full Duplex
Protocol: SNMP, HTTP, TCP/IP (IPv4/IPv6), FTP

Wireless LAN

Standard: IEEE802.11n/IEEE802.11g/IEEE802.11b
Security: WEP (64/128-bit)
WPA-PSK (TKIP/AES)
WPA2-PSK (TKIP/AES)

Options

2”/3” Roll Holder Set (RH2-34)
PosterArtist

User-Replaceable Items
• Ink Tank (PFI-340/PFI-740)
• Print Head (PF-06)
• Maintenence Cartridge (MC-30)

Operating System

Windows® 7 (32/64-bit), Windows 8.1 (32/64-bit),
Windows 10 (32/64-bit), Windows Server 2008 R2,
(32/64 bit), Windows Server 2012 (64-bit), Windows
Server 2016 (64-bit), Macintosh® OS X v10.10.5 – v10.12x

Printer Dimensions (H x W x D) and Weight

TZ-30000: 47” x 61” x 38”; 456 lb. (Approx.)
TZ-30000 MFP Z36: 51” x 63” x 38”; 478 lb. (Approx.)

Package Dimensions (H x W x D) and Weight

TZ-30000: 54” x 67” x 37”; 604 lb. (Approx.)
Z36 Scanner: 45” x 17” x 15”; 46 lb. (Approx.)

Power Supply

AC 100 – 240V (50 – 60 Hz)

Power Consumption

Maximum: 68 W or Less
Standby: 3.6 W or Less
Power Off: 0.3 W or Less (Executive Order Compliant)

Printing Software Utilities

Accounting Manager, Canon Print Service, Device
Management Console, Direct Print Plus, Free Layout
Plus, Media Configuration Tool, PosterArtist Lite
for Windows, PosterArtist (optional purchase), CPP
Publisher Select, Canon Printer Driver, CPP Driver
Select, Optimized Driver for AutoCAD, Printer Driver
Extra Kit

Media Feed

Roll Feed: Two Rolls, Front Loading
Cut Sheet: Front Loading

Media Width

Roll Feed: 8” – 36” (203 mm – 914 mm)
Cut Sheet: 8” – 36” (203 mm – 914 mm)

Media Cutter

Durable Dual-Blade Rotary Cutter

Media Thickness

0.07 mm – 0.8 mm

Media Core Sizes

2” and 3” Core Adapters Included

Maximum Roll Outer Diameter

6.9” or Less

Media Output

Front Output: Basket
Top Output: Top Delivery Tray

Scan Accuracy

+/- 0.1% : +/- 1 pixel

Maximum Scan Width

36”

Maximum Media Width

38”

Maximum Scan Length

315” (JPEG/PDF); 598” (TIFF)

Maximum Media Thickness

0.003” – 0.04” (0.07 mm – 1.0 mm)

Digital Imaging Technology

Contact Image Sensor (CIS) Technology
(SingleSensor Assembly)

Included Software

SmartWorks MFP Scan-to-Copy/File/Email with
Real-time Image Viewer; Supports TIFF, JPEG, TIFF G4,
and PDF

Scanner Operating System

Windows 10 LTSC

Scanner Interface Kit

Superspeed USB 3.0 (PC Connector Compatible with
USB 2.0 and USB 3.0 Sockets)

Scan Speed

• 24-bit Color @ 200 dpi: 3” (Per Second)
• 8-bit Grayscale and Monochrome @ 200 dpi:
13” (Per Second)

Copy Speed

24-bit Color @ 200 dpi: 6” (Per Second)

Scan Modes

• 16.7 Million Color RGB (24-bit)
• 256-level Grayscale (8-bit)
• Black and White (1-bit)

Color Space

sRGB

Maximum Scan Resolution

1200 dpi (Optical)

Scanner Power Consumption

Sleep: 0.2 W
Idle: 12.4 W
Scanning Color/Grayscale @ 200 dpi: 22.7 W/23.3 W

Scanner Dimensions (H x W x D)

6.1” x 41.6” x 9.9”

Scanner Weight

17.3 lb. (Approx.)
